4g Wi-fi router gigabit dual band 11AC 1200Mbps 5G vdsl modem router with qos, sim card slot and pci-e slot mtk router


4g Wi-fi router gigabit dual band 11AC 1200Mbps 5G vdsl modem router with qos, sim card slot and pci-e slot mtk router
US $63.49/ piece
US $63.49
Update :
Vendor :
Prod ID: 32953436270
Posted : 2019-02-17
✄ Check Discount
☑ Detail Product

This is a perfect day for going shopping. Here 4g Wi-fi router gigabit dual band 11AC 1200Mbps 5G vdsl modem router with qos, sim card slot and pci-e slot mtk router that you can obtain just for US $63.49 (update at Fri, 01 Feb 2019). This great product from and only available at upfrmgtspgn. For information and facts products, press button highlight and look what the some other said with this.

Spesification

Supports WDS: Yes
Wi-Fi Supported Frequency: 2.4G & 5G
Function: Firewall,VPN,QoS
Standards And Protocols: Wi-Fi 802.11b,Wi-Fi 802.11n,Wi-Fi 802.11ac,Wi-Fi 802.11g
Max. LAN Data Rate: 1000Mbps
Wired Transfer Rate: 10/100/1000Mbps
With Modem Function: No
LAN Ports: 4
Brand Name: ZBT
Supports WPS: No
Application: 3G
Type: Wireless
WAN Ports: 1 x10/100/1000Mbps
Package: Yes
Model Number: CSW-WR246
Wi-Fi Transmission Standard: 802.11ac
5G Wi-Fi Transmission Rate: 867Mbps
Number of USB Interfaces: 1 x USB 2.0
2.4G Wi-Fi Transmission Rate: 300 Mbps
2.4GHz chipset: MT7621/Dual core/880MHz
5G chipset: MT7612E
Firmware : English version
SIM Card Slot: 1
SD card slot: 1
Warranty period: 1 year
Memory: DDR3 512MB
FLASH: SPI 16MB(32MB)
Max. LAN Data Rate: 1000Mbps
3G 4G function: Support

Warm Reminder

The neutral product is Gigabit dual band openwrt wireless router. If you need 3g or 4g or want to use SIM card to dial out Internet, here also need 3g or 4g module.

As for 3g/4g, 3G can support 3g/2g, 4G can support 4g/3g/2g.

Please see the following adtapters, some countries will be sent original US Plug, we will match an (UK / AU) adapter plug for you.

Neutral(no 3G 4G): Gigabit+dual band openwrt wireless router, it doesn't support sim card.

3G Version:  3G 300mbps openwrt wireless router.

4G Asia version : 4G Gigabit dual band openwrt wireless router.

4G USA  version 1 : 4G Gigabit dual band openwrt wireless router.

4G USA version 2:   4G Gigabit dual band openwrt wireless router

Note:

If you don't know which version that you need to choose, here are some countries' version for your reference.

If your country is not mentioned and you don't know which version need to choose, please ask me and i will help you.

CSW-WR246 adopt the newest dual core MT7621 chipset, the main frequency is 880MHz, provide 5*10/100/1000Mbps Auto-MDI/MDIX Ethernet port, 1*USB 2.0 port, 1*Micro SD card slot,  1*Micro SD card slot, 1*Mini-PCIE slot, 1*SIM card slot.

Support IEEE802.11ac/n/g/b/a wireless protocol, max wireless rate could be 1200Mbps , 4×5Dbi high gain antennas , perform better and cover larger.

3G 4G Module Setting Guide

1. Connect to all the antennas correctly.

2. The sim card must insert firstly, and  the chip of the sim card should be downward,  then connect to the power. If you need to remove the sim card, in order to avoid damaging the SIM card, please remember to cut off the power before you remove sim card.

3. Insert IP address "192.168.1.1" into the browser,user name:root; password:admin

4. Click the Network--interfaces.

5. Dial up setting.

Shipping Item

1 x openWRT wireless router

1 x power supply

1 x product manual

1 x cable

Product Specification

2.4GHz chipset

MT7621/Dual core/880MHz

5G chipset

MT7612E

RAM

DDR3 512MB (Maximum DDR3 512MB)

FLASH

SPI 16MB  (Maximum 32MB)

Protocol

IEEE802.11ac/a/b/g/n

IEEE802.3, IEEE802.3u

Wireless rate

2.4G: 300Mbps

5G: 867Mbps

Work frequency

2.4GHZ, 5.8GHZ

Antenna

2*5dbi 2.4Ghz antennas

2*5dbi 5.8GHz antennas

Interface

1* 10/100/1000Mbps Auto-MDI/MDIX WAN port, 4* 10/100/1000Mbps Auto-MDI/MDIX LAN port,

1* USB 2.0 port, 1* SD Card Slot, 1*Mini-PCIE slot, 1*SIM card slot

LED

Power/2.4G/5G/WAN/LAN4/LAN3/LAN2/LAN1

Button

Reset

Powered by POE

NO

Maximum power consumption

12W

Power Adapter

DC 12V 2A

Housing size (L*W*H) and color

Size: 235*135*25.5mm

Color: Black silver (accept custom)

Factory setting

IP address: 192.168.1.1

User name/ pass word: admin/admin

WAN access way

PPPoE, Dynamic IP, Static IP, 3G/4G

Work mode

AP; ROUTER;

DHCP server

DHCP server Client list; Static Address distribution

System supported

Original SDK, openwrt, eCos

Virtual server

Port Forwarding DMZ main machine

Safety setting

Client filter

MAC Address Filter

URL Filter

Long-distance WEB management

DDNS

Support

WEB theme switch

Support

Bandwidth control

Support

Static routing

Support

System log

Support

Others

Mac clone

NTP Synchronize

Web firmware upgrade

Work environment

Operating Temperature: 0℃ ~ 40℃

Storage Temperature: -40℃~ 70℃

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing
